- Dual synthesis engines: two AWM2 (Advanced Wave Memory 2) engines and a 4‑operator FM engine
- 11 independent tracks (DRUM, SYNTH, DX, SAMPLER) for rich, layered arrangements
- 128‑step sequencer with pattern chaining and real‑time control
- Built‑in sampler with internal MEMS microphone and external audio input
- Over 2,000 preset sounds (expandable via downloadable packs) plus user sample slots
- Comprehensive effects: reverb, delay, master and single effects, 5‑band EQ, LP/HP filters
- USB‑C for power, audio interface and MIDI to host/device
- Bluetooth MIDI and Wi‑Fi for file transfer and remote control via companion SEQTRAK app
- Internal speaker and rechargeable lithium‑ion battery for mobile use
- Lightweight and compact with intuitive onboard controls
| Specification | Detail |
|---|---|
| Tone Engines | AWM2 & 4‑op FM |
| Maximum Polyphony | AWM2: 128 notes; FM: 8 notes |
| Tracks | 11 tracks |
| Preset Sounds | 2032 |
| User Sample Memory | 500 MB |
| Effects | Reverb ×12, Delay ×9, Master Effects ×85, Single Effects ×85, 5‑band EQ |
| Sequencer Steps | 128 |
| Connectivity | USB‑C (power, MIDI/audio), Headphones stereo mini, Stereo audio in, MIDI IN/OUT |
| Wireless | Bluetooth MIDI, Wi‑Fi (region‑dependent) |
| Speaker | 2.3 cm, 1 W built‑in speaker |
| Microphone | Internal MEMS mic |
| Power | Rechargeable lithium‑ion battery (2,100 mAh) |
| Battery Life | 3–4 hours |
| Dimensions (W × H × D) | 343 × 38 × 97 mm |
| Weight | 0.5 kg |
Boxed dimensions: approx. 420 × 90 × 165 mm
- Yamaha SEQTRAK unit
- USB‑C to USB‑C cable
- Dedicated MIDI converter cable
- Quick operation guide
- Safety guide
