- Features
- Specifications
- Dimensions
- Whats in the box
- 61 full-size, touch-sensitive organ-style keyboard (FSB) with multiple touch curves
- Large 7″ color wide VGA TFT touchscreen (800×480) with touch control
- 1,377 built-in voices + 56 Drum/SFX kits + 480 XG voices
- 128-note polyphony for rich, layered playback
- Advanced arranger styles with chord looper and pattern control
- Assignable joystick and knobs, plus 8 assignable buttons
- Expandable voice and style memory (internal ~4 GB)
- Recording: 16-track sequencer, WAV/MP3 audio recorder/player
- Comprehensive effects: reverb, chorus, DSP, EQ, and more
- Playback functions with pitch shift, time stretch, and vocal cancel
- USB TO HOST and USB TO DEVICE for storage and USB audio/MIDI
- Microphone & inch jack inputs plus main and sub outputs
| Specification | Detail |
|---|---|
| Keyboard | 61 keys, organ (FSB), touch-sensitive |
| Polyphony | 128 notes |
| Voices | 1,377 + 56 Drum/SFX + 480 XG |
| Tone Generation | AWM Stereo Sampling |
| Display | 7″ Color TFT VGA LCD (800×480), Touch |
| Sequencer / Recorder | 16-track MIDI + audio recording |
| Effects | Reverb, Chorus, DSP, EQ, Compressor |
| Connectivity | USB TO HOST, USB TO DEVICE, MIDI IN/OUT, LINE/MIC/AUX jacks |
| Speakers | Built-in amplifiers & speakers |
| Dimensions (W × D × H) | 1,017 × 431 × 139 mm |
| Net Weight | 11.6 kg (25 lb 9 oz) |
Approx. boxed dimensions: 1,174 × 511 × 246 mm
- Yamaha PSR-SX720 keyboard unit
- AC adaptor / power supply
- Music rest (sheet-music holder)
- User manual and warranty documentation
