- Features
- Specifications
- Dimensions
- Whats in the box
- 76 full-size touch-sensitive keys (velocity-sensitive: Soft / Medium / Hard / Off)
- 650 high-quality voices (including musical instruments, piano, drums, synths, etc.)
- 260 auto-accompaniment styles for backing tracks and rhythm accompaniment
- 125 preset songs and built-in lesson functions (e.g. “Keys to Success”, 3-Step Lesson)
- Super Articulation Lite Voices for expressive, realistic instrument articulation
- Dual, Split, & Duo mode — support for layered sounds or two-player/practice setups
- USB to HOST (MIDI/audio) connectivity — for DAW integration, recording, or use as MIDI controller
- AUX input, headphone out, and sustain pedal input — flexible connectivity for external sources and silent practice
| Specification | Detail |
|---|---|
| Number of Keys | 76 (organ-style) |
| Key Action | Touch-sensitive (velocity-sensitive) |
| Tone Generation | AWM Stereo Sampling |
| Maximum Polyphony | 48 notes |
| Number of Voices | 650 (Panel Voices + Drum/SFX + XGlite Voices + Arpeggio voices) |
| Accompaniment Styles | 260 preset styles |
| Preset Songs | 125 |
| Recording | Up to 5 songs, 2 tracks, approx. 10,000 notes total |
| Effects | 41 DSP types; 15 Reverb; 7 Chorus; Master EQ; 26 Harmony types |
| Arpeggio Types | 152 |
| Connectivity | USB to Host (MIDI & Audio), AUX In, Headphones/Output, Sustain Pedal Input |
| Power Supply | AC adaptor or 6 × “AA” batteries |
| Built-in Speakers | 2 × 12 cm speakers (2.5 W + 2.5 W amp) |
| Dimensions (W × H × D) | 1,148 × 105 × 317 mm |
| Weight | 5.2 kg (without batteries) |
Boxed dimensions: Not officially specified by manufacturer
- PSR-EW320 keyboard unit
- Music rest (sheet-music holder)
- AC adaptor (PA-130 or equivalent) — depending on region
- User manual / documentation
