- Features
- Specifications
- Dimensions
- Whats in the box
- 18‑channel digital mixing console with HDMI‑to‑USB video/audio capture and pass‑through
- 11 + 1 non‑motorized faders with 4.3″ touchscreen and five control knobs
- 4 mono + 4 stereo inputs plus 1 Sound Pad and 2 FX return channels
- Built‑in DSP effects: gate, compressor, EQ, reverb, amp simulation, and more
- USB audio interface: 18‑track USB main + 2‑track USB sub and microSD multi‑track recording/playback
- Bluetooth 5.0 audio input (A2DP) for wireless playback
- HDMI‑to‑USB pass‑through for real‑time audio/video capture
- Multiple analog inputs: 4 × combo Mic/Line, 4 × TRS Line, 4 × RCA Line
- Versatile outputs: 2 × XLR, 6 × TRS, and 4 × headphone outputs
- Scene recall, auto gain, clip safe, and simple/standard modes for fast setup
| Specification | Detail |
|---|---|
| Mixing Channels | 4 mono + 4 stereo + 1 Sound Pad + 2 FX returns |
| Busses | 1 stereo, 8 mix, 2 FX, 1 cue |
| Analog Inputs | 4 × XLR/TRS combo; 4 × TRS line; 4 × RCA line |
| Analog Outputs | 2 × XLR, 6 × TRS |
| Headphone Outputs | 4 × TRS |
| USB MAIN | 18‑track I/O @ up to 32‑bit/96 kHz |
| USB SUB | 2‑track I/O @ up to 16‑bit/48 kHz |
| microSD Recording | Up to 16‑track record / 2‑track playback |
| Bluetooth | Bluetooth 5.0 A2DP audio input |
| Video I/O | HDMI IN / HDMI THRU (audio/video via USB capture) |
| Display | 4.3″ touchscreen |
| Dimensions (W × H × D) | 335 × 96 × 319 mm |
| Net Weight | ≈ 4.1 kg |
Not officially published by Yamaha, but typically packed in approximate carton dimensions around 45 × 30 × 20 cm.
- MGX12V digital mixing console
- AC power adapter (PA‑300C)
- Quick start guide and safety documentation
- Steinberg software license cards (Cubase AI + WaveLab Cast + Basic FX Suite)
