- Handcrafted 1/2-inch true condenser capsule
- Ultra-thin 3-micron gold-sputtered diaphragm
- Transformerless Class-A circuitry
- Natural, balanced sound with consistent off-axis response
- Switchable -10 dB and -20 dB attenuation pads
- Switchable 80 Hz and 160 Hz low-cut filters
- All-metal housing with gold-plated XLR connector
- Designed for acoustic guitar, piano, drums, percussion, cymbals, overheads, strings, woodwinds, and choir
- Compatible with the sE8 omni capsule
| Specification | Detail |
|---|---|
| Microphone Type | Small-Diaphragm True Condenser |
| Capsule | Handcrafted 1/2-inch True Condenser |
| Polar Pattern | Cardioid |
| Frequency Response | 20 Hz – 20 kHz |
| Sensitivity | 25 mV/Pa (-32 dBV) |
| Maximum SPL | 139 / 149 / 159 dB SPL (0 / 10 / 20 dB pad) |
| Equivalent Noise Level | 13 dB |
| Dynamic Range | 126 / 136 / 146 dB (0 / 10 / 20 dB pad) |
| Signal-to-Noise Ratio | 81 dB |
| Low-Cut Filter | 80 / 160 Hz, 6 dB/octave, switchable |
| Attenuation Pad | 10 / 20 dB, switchable |
| Electrical Impedance | 110 Ohms |
| Recommended Load Impedance | >1 kOhms |
| Power Requirement | 48V Phantom Power (P48 according to IEC 61938) |
| Current Consumption | 2.7 mA |
| Connector | 3-pin Male XLR |
| Mic Diameter | 23 mm |
| Mic Length | 120 mm |
| Mic Weight | 141 g |
7.8 × 5.0 × 3.0 in (19.81 × 12.70 × 7.62 cm)
- sE8 microphone
- Mic clip with thread adapter
- Windscreen
