Professional Sound Engine: Includes rich presets from the XPS‑10 and JUNO‑Di, plus expanded pianos and world instruments.
Wave Expansion & Sample Import: Supports downloadable sound expansions and lets you import your own WAV multi-samples via USB.
Built-In 8-Track Phrase Sequencer: Easily create full arrangements and backing tracks without a computer.
Eight Phrase Pads: Instantly trigger audio samples or loops from USB—great for live performance.
Mic Input with Vocal Effects: Connect a microphone and use reverb, auto-pitch, and vocoder effects directly from the keyboard.
Real-Time Controls: Includes sliders, knobs, and a bright display for fast sound editing on the fly.
USB Audio/MIDI Interface: Record directly into your DAW and control your software using the keyboard.
128-Voice Polyphony: Ideal for complex layers and performances without dropped notes.
Split & Layer Options: Easily assign different sounds to keyboard zones or layer multiple tones.
Compact & Lightweight: Road-ready design with solid construction for mobile gigging.
Keyboard: 61 velocity-sensitive keys (no aftertouch)
Polyphony: 128 voices
Multitimbral: 16 parts
Tone Memory: Over 1,500 tones (user-expandable via waveform expansion)
Effects:
Multi-effects: 3 systems, 80 types
Chorus: 3 types
Reverb: 5 types
Master EQ and Mic effects (including vocoder & auto-pitch)
Phrase Pads: 8 pads (USB audio playback or sample triggering)
Sequencer: 8-track phrase sequencer + rhythm track
Connectivity:
1 × Mic Input (1/4″)
1 × Line Output L/MONO, R (1/4″)
1 × Headphones (stereo 1/4″)
1 × MIDI In/Out
1 × USB to Host (Audio/MIDI)
1 × USB Memory Port
1 × Pedal Hold jack
1 × Assignable Control Pedal jack
Display: 16-character × 2-line LCD with backlight
Power Supply: AC adapter or 8 AA batteries
Power Consumption: 1,000 mA
Dimensions (W × D × H): 1,002 × 251 × 93 mm
1 × Roland XPS‑30 Synthesizer (61-key)
1 × AC Adapter
1 × Power Cord (for adapter)
1 × Owner’s Manual
1 × Leaflet with safety information
