Massive Sound Library: Includes over 1,500 high‑quality tones, including heritage sounds from the JUNO‑Di, D‑50, XP series, and a wide selection of ethnic instruments and regional tuning banks.
Sample Import Support: Easily import your own WAV samples (up to 32 MB) via USB flash memory to create custom sounds and play them across the keyboard.
Audio Pad: Six trigger pads let you launch backing tracks, loops, or internal rhythms (WAV, AIFF, MP3), with looping and playback control.
Hands-On Live Interface: Dedicated buttons for favorites, sound layering, splits, octave shift, transpose, and nine Sound Modify sliders for real-time filtering, level, and expression control.
Arpeggiator + Rhythm: Built-in arpeggio engine with 128 presets and integrated rhythm patterns (24 groups × 6), great for live and creative composition.
Effects Engine: Three independent multi‑effect processors (78 types each), plus global chorus (3 types) and reverb (5 types) for deep tonal shaping.
128-Voice Polyphony & 16-Part Multitimbrality: Enables rich layering, split zones, and multitrack performances without note-dropping.
User Scale Function: Create and store up to nine alternative tunings, with micro‑tone adjustment (±50 cents), ideal for ethnic and world music applications.
USB Audio/MIDI Interface: Connect directly to DAWs or MIDI software via USB; also supports traditional MIDI In/Out.
Compact & Lightweight: Slim and rugged design (~4 kg), portable and ideal for gigging and travel.
Keyboard: 61 velocity-sensitive keys (no aftertouch)
Polyphony: 128 voices
Multitimbral: 16 parts
Preset Tones: Over 1,500 (including pianos, synths, organs, world instruments)
User Sample Import: WAV format, up to 32 MB total (via USB flash)
Audio Pads: 6 pads (for MP3/WAV/AIFF playback and sample triggering)
Effects:
Multi-Effects: 3 systems, 78 types each
Chorus: 3 types
Reverb: 5 types
Arpeggiator: 128 presets
Rhythm Patterns: 24 groups × 6 patterns
User Scale Tuning: 9 programmable scales with fine-tuning
Display: 16-character × 2-line LCD
Connectivity:
1 × Mic Input (1/4″)
1 × Line Output L/MONO, R (1/4″)
1 × Headphones Output (1/4″ stereo)
1 × USB to Host (for MIDI/audio)
1 × USB Memory Port (for sample/audio playback)
1 × Pedal Hold jack
1 × Control Pedal jack
1 × MIDI In/Out
Power Supply: AC adapter or 8 × AA batteries
Power Consumption: 1,000 mA
Dimensions (W × D × H): 1,002 × 251 × 93 mm
1 × Roland XPS‑10 Synthesizer (61-key)
1 × AC Adapter
1 × Power Cord
1 × Owner’s Manual
