- Specifications
| Model No. | PCH-18S-PRO |
|---|---|
| Type | 18" subwoofer, active |
| Frequency Response (-6dB) | 35 Hz - 200 Hz |
| Max. SPL (1m, free space) | 130 dB |
| Power Output (RMS) | 1200W |
| Impedance | 8 Ohms |
| Transducer LF | 18" Alu. frame Subwoofer, 4" VC |
| Amplifier | Class-D mono amplifier |
| DSP Module | DSP-100, 96 kHz, 24-bit DSP processor with 4 preset modes |
| Protection | Short circuit, overheating, over-current |
| Controls | Power On / Off switch, DSP modes switch, low pass frequency, subwoofer level, phase switch |
| Indicators | Power, signal, limit, DSP modes |
| Audio Input / Output | Left / Right XLR line input, Left / Right XLR line output, 2 * XLR output high pass 120Hz |
| Power Supply | 100~260V 60/50 Hz |
| Enclosure | 18mm plywood cabinet, sand lacquer painting |
| Grille | Metal grille with acoustic fabric |
