LISTEN ACOUSTIC PCH-15PRO Specifications
| Model No. | PCH-15PRO |
| Type | 15" 3-way full range speaker box |
| Frequency Response (-6dB) | 50 Hz – 20 kHz |
| Max. SPL (1m, free space) | 135 dB |
| Power Output (RMS) | 800 W |
| Impedance | 4 Ohms |
| HF Transducer | 1.75" Titanium Diaphragm driver |
| MF Transducer | 10" woofer, 2" voice coil |
| LF Transducer | 15" woofer, 3" voice coil |
| Amplifier | Class-D 3-way amplifier |
| DSP Module | DSP-100, 96 kHz, 24-bit DSP with Music, Live, Speech, Flat modes |
| Protection | Short circuit, overheating, over-current, soft boot, LCC, PFC, separate supply |
| Controls | Power On/Off, DSP mode switch, line level, mic/line switch |
| Indicators | Signal, Limit, DSP modes |
| Audio Input / Output |
2 × Combo XLR/Jack input 1 × Aux line input 1 × XLR output |
| Optional Function | Bluetooth 5.2 + TWS |
| Power Supply | 100–260V, 60/50 Hz |
| Enclosure | H-PP with painting, 35 mm pole mount, top & side handles |
| Grille | Metal grille with acoustic fabric |
