- Features
- Specifications
- Dimensions
- Whats in the box
- High-quality Bluetooth audio streaming for background music or live accompaniment
- QuickSmartDSP with 4 presets, sub/top system-match, 2-band EQ, 5 user memories, limiter metering, and master volume via LCD
- 1,000 W Class-D amplifier, delivering up to 126 dB peak SPL
- SST (Signal Synchronized Transducers) waveguide for precise coverage and low distortion
- Three built-in handles in a rugged composite cabinet for portability
- Portable design optimized for stand, floor monitor, or wall mount use
| Specification | Detail |
|---|---|
| Frequency Response (-3 dB) | 65 Hz ‒ 18 kHz |
| Frequency Range (-10 dB) | 50 Hz ‒ 20 kHz |
| Maximum SPL | 126 dB |
| Coverage (H × V) | 90° × 60° |
| Power Rating | 1,000 W Class-D |
| LF Driver | EVS-12K, 300 mm (12″) woofer |
| HF Driver | DH-1K compression driver |
| Connectors | 2 × XLR/TRS combo, 1 × 3.5 mm aux in, 1 × XLR link out |
| Enclosure Material | Polypropylene |
| Grille | 18-gauge steel, powder coated |
| Dimensions (H × W × D) | 610 × 356 × 356 mm |
| Net Weight | 15.6 kg |
| Power Consumption | 100–240 V~, 50–60 Hz, 0.8–0.5 A |
Boxed dimensions: ~ 610 × 356 × 356 mm
- ZLX-12BT powered loudspeaker
- Power / IEC cable
- User manual / safety guide
