- 2-way bi-amped powered loudspeaker with bass-reflex enclosure
- Newly developed 2,000W Class-D amplifier
- 12" high-durability low-frequency driver
- 1.75" compression driver with wide-dispersion horn
- Maximum SPL of 134 dB
- FIR-X™ tuning with linear phase FIR filters
- 96 kHz DSP processing with multiple EQ presets
- Drive Motion Calibration™ for improved low-frequency accuracy
- D-Remote app compatibility for iOS and Android
- Lightweight injection-molded enclosure with monitor wedge design
| Model | DXR12 MK3 |
| Speaker Type | 2-Way, Bi-Amped Powered Loudspeaker, Bass-Reflex |
| LF Driver | 12" Cone, 2.5" Voice Coil |
| HF Driver | 1.75" Compression Driver |
| Amplifier | Class-D |
| Peak Power Output | 2,000 W |
| Frequency Range (-10 dB) | 50 Hz – 20 kHz |
| Maximum SPL | 134 dB SPL |
| Coverage | 90° H × 60° V |
| Crossover | 1.8 kHz (FIR-X™) |
| DSP | 96 kHz DSP with FIR-X™ Tuning and Drive Motion Calibration™ |
| Power Requirements | 100–240 V AC, 50/60 Hz |
| Product Dimensions (L × W × H) | 350 × 365 × 600 mm |
| Product Weight | 17.4 kg |
| Package Dimensions (L × W × H) | Not specified by manufacturer |
| Shipping Weight (with Box) | Not specified by manufacturer |
- Yamaha DXR12 MK3 Powered Loudspeaker
- AC Power Cord
- Owner's Manual
- Warranty Documentation
