- 4-channel Class-D power amplifier with integrated DSP.
- 300 watts per channel output.
- Supports both low-impedance and 70V/100V distributed systems.
- Built-in DSP including EQ, crossover, delay, limiter, and SmartBass processing.
- Integrated matrix mixer with flexible routing capabilities.
- Opti-Voice paging for smooth music-to-announcement transitions.
- Load-independent outputs eliminate the need for bridging.
- I-Share technology allows combining two channels for increased power output.
- Browser-based configuration utility with Ethernet connectivity.
- Compatible with Bose ControlCenter wall controllers.
| Amplifier Class | Class D |
| Channels | 4 |
| Power Output | 300 W × 4 |
| Maximum Peak Power | 600 W per Channel |
| Frequency Response | 20 Hz – 20 kHz (±1 dB) |
| THD+N | < 0.04% |
| Dynamic Range | ≥ 100 dB |
| Channel Separation | > 80 dB @ 1 kHz |
| Inputs | 4 Balanced, 2 Unbalanced RCA |
| Outputs | 4 Speaker Outputs, 2 Auxiliary Outputs |
| DSP | EQ, Delay, Crossover, Limiter, SmartBass, Matrix Mixer |
| A/D & D/A Conversion | 24-bit / 48 kHz |
| Audio Latency | < 1 ms |
| Network Port | RJ45 Ethernet |
| Operating Modes | 4–8 Ω, 70V, 100V |
| Power Requirement | 100–240 VAC, 50/60 Hz |
| Unit Dimensions | 42.0 × 48.3 × 4.4 cm |
57.0 × 54.0 × 13.0 cm
- 1 × Bose PowerSpace P4300+ Amplifier
- 1 × IEC Power Cord
- 5 × 3-Pin Euroblock Connectors
- 1 × 4-Pin Euroblock Connector
- 1 × 2-Pin Euroblock Connector
- 2 × I-Share Jumpers
- 10 × Terminal Forks (14–16 AWG)
- 1 × Installation Guide
