ESI U86 XT USB COMPUTER SOUNDCARD

ESI U86 XT USB COMPUTER SOUNDCARD

₱23,500.00 PHP
₱23,500.00 PHP
Sale Sold out

Meet the ESI U86 XT, a professional-grade USB 2.0 audio interface tailored for demanding recording sessions. With its expansive I/O configuration—8 inputs and 6 outputs—plus dual mic preamps, Hi-Z instrument jacks, MIDI support, and clean 24-bit/96 kHz audio conversion, it's perfect for complex home studios, podcasters, and live performers who require both flexibility and pristine sound.

View full details
  • Features
  • Specifications
  • Dimensions
  • Whats in the box

  • 8 inputs / 6 outputs via USB 2.0 Hi-Speed, all available simultaneously
  • 2 professional mic preamps with switchable +48 V phantom power
  • 2 Hi-Z instrument inputs (combo XLR/TRS) for guitars or line signals
  • 8 balanced ¼″ TRS line inputs; 6 balanced ¼″ TRS line outputs
  • Coaxial S/PDIF digital input and output (RCA)
  • Front-panel headphone output with integrated monitoring mixer
  • 16-channel MIDI I/O (1 MIDI In, 1 MIDI Out)
  • Low-latency drivers: EWDM, DirectWIRE, ASIO 2.0, WDM, CoreAudio support
  • Dynamic Range: ADC 107 dB(A); DAC 112 dB(A)
  • Bundled software: Bitwig Studio 8-Track, inTone 2 ESI Edition, Deckadance LE
  • External DC power required (included) for operation

  • Resolution: 24-bit / 96 kHz
  • Analog I/O:
    • 2 combo inputs (mic/line/Hi-Z)
    • 8 line inputs (¼″ TRS)
    • 6 line outputs (¼″ TRS)
  • Digital I/O: 1 × S/PDIF in; 1 × S/PDIF out (RCA)
  • Monitoring mixer with front-panel mix control
  • MIDI: 1 × DIN In, 1 × DIN Out
  • Drivers & Compatibility: ASIO 2.0, EWDM, WDM, DirectWIRE (Windows); CoreAudio (macOS)
  • Power Supply: External 12 V DC required

Approx. 31.0 cm (W) × 14.5 cm (D) × 4.5 cm (H)

  • ESI U86 XT USB audio interface
  • DC power adapter (12 V, ≥3 A)
  • USB cable
  • Licenses for Bitwig Studio 8-Track, inTone 2 ESI Edition, Deckadance LE
  • User manual
