- 8 × 3.5″ neodymium drivers in a full‑range column for even coverage
- 12″ subwoofer for deep, articulate bass
- 1,000 W Class‑D power amplifier (500 W LF + 500 W HF)
- Integrated 8‑channel digital mixer with pro-grade preamps
- 30 built-in FX presets (reverb, delay, chorus, etc.)
- Bluetooth audio streaming for playback
- QuickSmart Link support via RJ45 for stereo linking and remote control
- QuickSmart Mobile app for remote DSP and mix control
- Durable composite column, aluminum pole, and 15 mm plywood sub
- Magnetically assisted latching of column to sub via pole
| Specification | Detail |
|---|---|
| Frequency Response (‑3 dB) | 43 Hz – 20 kHz |
| Frequency Range (‑10 dB) | 37 Hz – 20 kHz |
| Maximum SPL | 127 dB |
| Coverage (H × V) | 120° × 40° |
| Amplifier Power | 1,000 W Class‑D |
| LF Channel Rating | 500 W |
| HF Channel Rating | 500 W |
| Crossover Frequency | 200 Hz |
| Connectors |
4 × XLR/TRS combo mic/line 2 × XLR/TRS stereo line 1 × ¼″ TRS Hi-Z 1 × stereo RCA 1 × 3.5 mm stereo 1 × Bluetooth stereo in 1 × ¼″ footswitch 1 × XLR mix out 1 × XLR aux out 1 × RJ45 QuickSmart Link |
| Enclosure | Column: Composite • Pole: Aluminum • Sub: 15 mm plywood |
| Grille | Steel, powder-coated (black or white) |
| Dimensions (Assembled) | 2045 × 345 × 471 mm |
| Net Weight | 26.25 kg |
| Power Consumption | 100–240 V AC, 50–60 Hz, 1.5–0.6 A |
Boxed dimensions: not fully disaggregated, but sub is 530 × 345 × 471 mm; full system assembled 2045 × 345 × 471 mm
- EVOLVE 50M column array
- 12″ subwoofer
- Telescoping aluminum pole (2-section)
- Power cable
- Protective bag for column + pole
- User manual
