- High-efficiency 1,200 W Class-D power amplifier
- Dual XLR/TRS combo jacks + stereo RCA input for flexible signal routing
- QuickSmartDSP with presets (Music, Live, Speech, Club), 3-band EQ, and five user-programmable memories
- QuickSmart Mobile app support via Bluetooth for remote DSP control
- SST (Signal Synchronized Transducers) waveguide for tight 90° × 60° coverage
- Polypropylene enclosure with three M10 suspension points and built-in carry handles
- Lightweight design while maintaining rugged construction
| Specification | Detail |
|---|---|
| Frequency Response (‑3 dB) | 55 Hz – 16 kHz |
| Frequency Range (‑10 dB) | 48 Hz – 19 kHz |
| Maximum SPL (1 m) | 132 dB |
| Power Rating | 1,200 W |
| LF Driver | EVS‑15M 15″ woofer |
| HF Driver | 1″ titanium compression driver |
| Crossover Frequency | 1,600 Hz |
| Input Connectors | 2 × XLR/TRS combo, 1 × stereo RCA |
| Output | 1 × XLR link |
| Coverage (H × V) | 90° × 60° |
| Enclosure | Polypropylene composite |
| Grille | 18 AWG steel, powder-coated |
| Suspension | 3 × M10 fly points |
| Dimensions (H × W × D) | 710 × 423 × 384 mm |
| Net Weight | 18.9 kg |
| Power Consumption | 100–240 V~, 50–60 Hz |
Boxed dimensions: approximately 71.0 × 42.3 × 38.4 cm
- ELX200‑15P powered speaker
- Power cable (IEC)
- User manual and warranty documentation
